AUSTAR, introducing the advanced cleanroom technologies from Europe in terms of cleanroom engineering services, produces and constructs pharmaceutical cleanrooms for Italian delta2000 system in China, and is the exclusive agent for the GRP cleanroom products of MRC Company's Dubai factory in China. With a technical service team of more than 150 personnel, a comprehensive cleanroom design optimization, material providing, or clean engineering construction services can be delivered.

The whole system has three materials, i.e. pre-coating steel panel, HPL melamine resin panel and GRP glass panel. According to the different production process and environment requirements of clients, the products can be customized or combined in full compliance with the requirements of EU GMP, China CGMP and US FDA standards. The whole process can provide complete services of design, secondary optimization, BIM modeling, layout design and construction drawing node design.

… More … Retract

50mm anti-shedding precoating panel system

System features:

  • High quality surface coating: Ag silver ion antibacterial plate, ESD anti-static, with PVDF coating of good VHP resistance;

  • 0.8mm hot-dip galvanized keel; in which the multi-channel bending strength is relied on the strength of ceiling board > 150kg /㎡;

  • Non-standard customization: embedded stiffeners, embedded various models of wire pipes, reinforcement modules;

  • The steel angle pieces and cast aluminum angle pieces cooperate with anti-falling structure; which strength and fire resistance are superior of class A;

  • The panel shall be matched with the keel reverse buckle structure to avoid glue overflow and filler leakage and meet the solid sealing requirements;

  • All auxiliary components meet the smoothness, without dead angle, easy to clean and no air leakage of the whole system;

  • It can provide multi scheme selection and matching with the clean door and window system;

  • The designed service life is more than 10 years.

Application field: pharmaceutical and chemical industry, construction of clean room of general laboratory.

… More … Retract

50mm anti-shedding HPL panel system

System features:

  • High quality HPL surface: rust resistant, impact resistant, scratch resistant, high flatness, Ag silver ion antibacterial surface, ESD antistatic surface, excellent VHP resistance;

  • The unique physical anti falling structure makes the carrying capacity of ceiling system more than 200kg / ㎡;

  • Non-standard customization: good cutting performance with embedded stiffeners and embedded various models of wire pipes, and reinforcement modules;

  • Cast aluminum adjustable angle fitting with anti-falling structure; fire rating B; fire rating of composite fire board can reach A2;

  • The panel is matched with the keel reverse buckle structure to avoid glue overflow and filler leakage and meet the solid sealing requirements;

  • All auxiliary components shall meet the smoothness, no dead angle, easy to clean and no air leakage of the whole system;

  • With the clean door and window system, more than 70 colors can be selected and matched;

  • The designed service life is more than 20 years.

Application fields: Construction of clean rooms in biopharmaceuticals, hospitals and laboratories.

… More … Retract

150mm GRP panel system

System features:

  • Glass fiber laminating material, with high flatness and excellent impact resistance;

  • It has good chemical resistance, especially acid and alkali resistance and 100% spray resistant H2O2 sterilizing agent;

  • Excellent furniture equipment integration function; system consistency (furniture equipment is also non-standard custom GRP material);

  • The integrated forming technology can reduce 70% of the joint gaps of the connecting components; the air tightness is extremely superior;

  • Depth customizable performance; random color combination;

  • Customize independent insulation free return air system with HAVC (150 mm return air unit).

Application fields: biomedicine, animal room, chemical laboratory, aerospace, high precision instrument clean room construction.
